    Pathfinder in jBPM 6 Simulation showing extra paths

    Juby Joseph Newbie

      Hi,

      After I create a model in jBPM6, and see the different paths using the pathfinder. I can notice that sometimes at XOR gateways, both paths from the gateway are highlighted. Is this correct behavior?



      For example, below you can see that Task E and Task F are highlighted at the same time, meaning both tasks are part of 1 path.
