    Sticky session with proxypass

    ratso May 7, 2010 4:25 AM

      Hello,



      I installed mod_cluster 1.1.0.CR1 (binary package for linux x86) and tomcat 6 (JDK 1.6.0_20). Note that I had to apply patch MODCLUSTER-143 and re-build the java side in order to run mod_cluster with tomcat.



      mod_cluster works just fine when configured with CreateBalancers set to 2.

      But when CreateBalancers is set to 1 and ProxyPass is used to define the cluster name in a virtualhost then the session is no more sticky and requests are balanced to all back-end tomcats.



      I enabled httpd debug (see attached log file) and figured out that even though the JSESSIONID cookie is found, mod_cluster does not found any route and a new session (new JSESSIONID cookie) is created for each requests.



      I tried different proxypass/proxypassmatch configurations but I was not able to enable sticky session. Am I missing something with the proxypass directive?



      Thanks for your help.



      Tomcat routes

      <Engine name="Catalina" defaultHost="localhost" jvmRoute="tomcat1">
      <Engine name="Catalina" defaultHost="localhost" jvmRoute="tomcat2">



      Tomcat mod_cluster listener

      <Listener className="org.jboss.modcluster.catalina.ModClusterListener"
              balancer="mycluster"
              advertise="false"
              proxyList="192.168.20.128:6666,192.168.20.129:6666"
              stickySession="true"
              excludedContexts="ROOT,manager,host-manager"
              />



      Apache mod_cluster configuration

      Listen *:6666
      <VirtualHost *:6666>



              KeepAliveTimeout 60
              MaxKeepAliveRequests 0



              CreateBalancers 1
              AdvertiseFrequency 5



              ServerAdvertise Off



              <Location />
                      Order Deny,Allow
                      Allow from All
              </Location>



              <Location /mod_cluster-manager>
                      SetHandler mod_cluster-manager
                      Order deny,allow
                      Allow from all
              </Location>



      </VirtualHost>



      Listen *:6667
      <VirtualHost *:6667>
              <Location />
                      Order Deny,Allow
                      Allow from All
              </Location>


              ProxyPass /tests/ balancer://mycluster/tests/ stickysession=JSESSIONID|jsessionid
      </VirtualHost>
